Following on the experience and success with its dielectrics in the field of electrical discharge machining (EDM), oelheld has now set itself new targets. Whereas high-quality hydrocarbons have been successfully used for decades in cavity-sinking EDM, water is still used in wire EDM – and that despite the numerous associated disadvantages.
Particularly when machining carbide metal, cobalt leaching consequently causing corrosion present a problem that is difficult to overcome. That is why oelheld together with leading companies in the EDM field and the University of Louvain (Belgium) decided to solve this problem and set up a research project to develop a hydrocarbon-based dielectric that is designed specifically for the wire EDM technology.
The service lives of carbide punches, in particular, can be enormously prolonged by preventing cobalt leaching. Laborious and cost-intensive deionisation of the water with resins, corrosion protection – before, during and after machining – and frequent changing of the medium are now things of the past thanks to this development. IonoFil as dielectric allows smaller spark gaps to be used, thus permitting far better precision machining, e.g. with closer radii. The quality of the surfaces increases to the same extent, with peak-to-valley roughnesses of down to RaMAX 0.1 μm being achieved far faster and easier than with water.
A convincing argument, particularly at a time when the industry is making ever higher quality demands on its suppliers and on the manufactured parts.
no cobalt leaching with carbide metal
better surface qualities
no corrosion on workpieces and the machine
better precision machining thanks to smaller spark gaps
no microbiological attack
reduced thermal shock
less heat cracking
Makino UPV-3
Makino UPV-5
Mitsubishi MX600
Seibu M25LP
Sodick AP200L
Sodick AP250L
GFMS
FI2050TW
CUT 1000 OilTech
CUT 2000 OilTech
